TVBF25

Rubber button with soft touch feeling
Normally closed and normally open type
Dustproof contacts sealed structure
Reflow solderable

Healthcare equipment
Care（wheelchairs,beds)
Analysis,test equipment
Medical equipment

Items		Standard
Operating temperature range		-30℃ to +85℃
Electrical performance	Rating	50mA. 12V DC
	Insulation resistance	100MΩ min. 100V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	A:B:E=100,000Cycles C=50,000Cycles
Mechanical performance	Operating force	A:90gf B:180gf C:250gf
Mechanical performance	Travel	0.3±0.1mm
