TVDM04

6x6mm, surface mounting type
Ground pin available
Reflow solderable

Visual
Audio
Pro audio

Items		Standard
Operating temperature range		-30℃ to +85℃
Electrical performance	Rating	50mA. 12V DC
	Insulation resistance	100MΩ min. 100V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	A:B:D:E:J=1,000,000Cycles C:G=500,000Cycles H:I=300,000Cycles
Mechanical performance	Operating force	A:90gf B:180gf C:250gf D:70gf E:130gf G:320gf H:400gf I:520gf J:160gf
Mechanical performance	Travel	0.25±0.1mm
