TVCP02

Surface mounting type
Compact size 4.5x4.5mm for high dentisy mounting
Partial output terminal can be used as jumper pin

Visual
Audio
Pro audio

Items		Standard
Operating temperature range		-30℃ to +85℃
Electrical performance	Rating	50mA. 12V DC
	Insulation resistance	100MΩ min. 100V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	B=300,000Cycles C=100,000Cycles
Mechanical performance	Operating force	B:180gf C:250gf
Mechanical performance	Travel	0.2±0.1mm
