TVBM17

Low profile of 2.5mm height
Compact size 3.7x6mm for high density mounting
Vertical Push type
Anti-ESD ground terminal available

Visual
Audio
Pro audio

Items		Standard
Operating temperature range		-30℃ to +85℃
Electrical performance	Rating	50mA. 12V DC
	Insulation resistance	100MΩ min. 100V DC
	Dielectric strength	250V AC for 1 min.
	Contact resistance	100mΩ max.
Durability	Lifetime	A:B:D:E=100,000Cycles C:G:50,000Cycles
Mechanical performance	Operating force	A:90gf B:180gf C:250gf D:70gf E:130gf G:320gf
Mechanical performance	Travel	0.25±0.1mm
